Standards: |
DIN7504N - phillips pan head self-drilling screw
DIN7504P - phillips flat countersunk head self-drilling screw
DIN7504K - hexagon washer head self-drilling screw
ISO15481 - phillips pan head self-drilling screw
ISO15482 - phillips flat countersunk head self-drilling screw
ISO15483 - phillips raised countersunk head self-drilling screw
ISO15480 -
hexagon washer head self-drilling screw
|
Heads: |
Hexagon, pan, countersunk, raised CSK (countersunk), or special on request
|
Drives: |
Cross recessed, phillips, phillips+slot combination, pozidrive, or special on request |
Threads: |
Self-tapping screw threads |
Size: |
ST2.2~9.5; No.4~10 |
Length: |
Metric: max. 120mm; UNC: max. 5" |
Material: |
SS304, SS316 |
|
|
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
